BendPak MDS-6LP Mid-Rise Open-Center Lift
The BendPak MDS-6LP is a high-performance mid-rise open-center scissor lift, designed for superior accessibility and efficiency. With a 6,000 lb. lifting capacity, longer platforms, and an extended lift point spread, this lift provides a secure and stable lifting experience for a wide variety of vehicle types, including those with longer wheelbases.
Unlike conventional scissor lifts that struggle to lift low-clearance vehicles, the MDS-6LP features a pivoting kicker mechanism, providing additional lift force during the first six inches of movement. This ensures smooth and reliable lifting, even from a collapsed position.
This mid-rise lift is perfect for repair shops and garages looking for a compact yet powerful lifting solution. Its removable approach ramps allow for a flush-mount setup, providing more working space around the vehicle when necessary.
Key Features & Benefits
- 6,000 lb. Load Capacity – Capable of lifting most cars, SUVs, and light trucks.
- Open-Center Design – Provides easy access to undercar components.
- Extended Lift Point Spread – Accommodates vehicles with long wheelbases safely.
- Four Solid Steel-Scissor Support Bars – One of the strongest mid-rise lifts in its class.
- Dual Master Hydraulic Cylinder – Works with dual equalizing cylinders for a level and stable lift.
- Solid-Steel Safety Lock Bars – Automatically engage during ascent for added security.
- Stainless-Steel Pneumatic Cylinders – Allow simultaneous safety lock release during descent.
- Push-Button Safety Lock Release – Eliminates the need for manual lock handles or release bars.
- Pivoting Kicker Mechanism – Provides extra lift force for low-clearance vehicles from a collapsed position.
- Removable Approach Ramps – Easily converts the lift into a flush-mount setup for better workspace efficiency.
- Compact Design – Perfect for garages with limited space while offering full functionality.
Why Choose the BendPak MDS-6LP?
The BendPak MDS-6LP is a must-have for professionals and automotive enthusiasts who need a versatile, space-efficient mid-rise lift. With its solid steel frame, advanced hydraulic system, and innovative lifting technology, this lift outperforms traditional scissor lifts by ensuring smooth, level, and secure lifting for a wide range of vehicles.
If you need a compact, reliable, and heavy-duty mid-rise lift, the BendPak MDS-6LP delivers exceptional performance and convenience.
Technical Specifications
| Specification | Measurement / Detail |
|---|---|
| Lifting Height (Min.) | 5 in |
| Lifting Height (Max.) | 35 in |
| Length | 70 in |
| Width | 67 in |
| Load Capacity | 6,000 lbs. |
| Voltage Requirement | 208-240V |
| Air Requirement | Min. 50 psi, 10 CFM at installation |
Final Thoughts
The BendPak MDS-6LP is an innovative, high-performance mid-rise lift offering superior strength, stability, and flexibility. Whether you’re performing wheel and brake work, undercar inspections, or maintenance, this lift provides unmatched accessibility and lifting power in a space-saving design.
